| PartNumber | HM185WX1-400 |
| Marca | BOE |
| mărimea | 18.5 |
| Aplicație | DMPC |
| Rezoluţie | 1366×768 |
| Compoziţie | LCM |
| Luminozitate | 200 |
| CR | 600:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | BOE |
| model de panou | HM185WX1-400 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 18.5 inch |
| rezoluţie | 1366(RGB)×768 , WXGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 409.8×230.4 mm |
| contur | 430.4×254.6×11.4 mm |
| suprafaţă | Antiglare (Haze 25%), Hard coating (3H) |
| luminozitatea | 200 cd/m² (Typ.) |
| Raport de contrast | 600:1 (Typ.) |
| culorile afișajului | 16.7M (6-bit + Hi-FRC), CIE193172% |
| timp de raspuns | 1.5/3.5 (Typ.)(Tr/Td) |
| unghi de vedere | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 10S4PWLEDWithout Driver |
| interfață de semnal | LVDS (1 ch, 8-bit), 30 pins |
| tensiune de intrare | 5.0V (Typ.) |
| aplicarea | DMPC |
| HM185WX1-300 | BOE | 18.5 | 1366×768 |
| HM185WX1-400 | BOE | 18.5 | 1366×768 |
| LC185EXN-SCA1 | LG Display | 18.5 | 1366×768 |
| LM185WH1-TLA1 | LG Display | 18.5 | 1366×768 |
| LTM185AT01 | Samsung | 18.5 | 1366×768 |
| M185BGE-L10 | Innolux | 18.5 | 1366×768 |
| M185BGE-L22 | Innolux | 18.5 | 1366×768 |
| M185XTN01.2 | AUO | 18.5 | 1366×768 |
| M185XW01 V5 | AUO | 18.5 | 1366×768 |
| MT185GW01 V.0 | Innolux | 18.5 | 1366×768 |
| FLC44SXC8V | Fujitsu | 17.4 | 1280×1024 |
| LM201U05-SLL1 | LG Display | 20.1 | 1600×1200 |
| LM220WE3-TLA1 | LG Display | 22.0 | 1680×1050 |
| LM300WQ3-STA1 | LG Display | 30.0 | 2560×1600 |
| LQ170E1LG18 | SHARP | 17.0 | 1280×1024 |
| LTM185AT01 | Samsung | 18.5 | 1366×768 |
| LTM220MT09 | Samsung | 22.0 | 1680×1050 |
| M190PP01 V0 | AUO | 19.0 | 1440×900 |
| M215H1-L02 | Innolux | 21.5 | 1920×1080 |
| M215HNE-L30 | Innolux | 21.5 | 1920×1080 |
