| PartNumber | LM300WQ3-STA1 |
| Marca | LG Display |
| mărimea | 30.0 |
| Aplicație | DMPC |
| Rezoluţie | 2560×1600 |
| Compoziţie | LCM |
| Luminozitate | 300 |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | CCFL |
| Interfață | TMDS |
| marca panoului | LG.Philips LCD |
| model de panou | LM300WQ3-STA1 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 30.0 inch |
| rezoluţie | 2560(RGB)×1600 , WQXGA |
| modul de afișare | S-IPS, Normally Black, Transmissive |
| Zonă activă | 641.28×400.8 mm |
| contur | 677.3×436.8 mm |
| suprafaţă | Antiglare (Haze 13%), Hard coating (3H) |
| luminozitatea | 300 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193192% |
| timp de raspuns | 6/6 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 16 pcsCCFLEmbedded (Inverter) |
| interfață de semnal | Dual Link TMDS, 45 pins |
| tensiune de intrare | 18.0V (Typ.) |
| rohs: | |
| aplicarea | DMPC |
