| PartNumber | M185BGE-L10 |
| Marca | Innolux |
| mărimea | 18.5 |
| Aplicație | DMPC |
| Rezoluţie | 1366×768 |
| Compoziţie | LCM |
| Luminozitate | 200 |
| CR | 700:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | CHIMEI INNOLUX |
| model de panou | M185BGE-L10 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 18.5 inch |
| rezoluţie | 1366(RGB)×768 , WXGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 409.8×230.4 mm |
| contur | 430.37×254.6×11 mm |
| suprafaţă | Antiglare (Haze 25%), Hard coating (3H) |
| luminozitatea | 200 cd/m² (Typ.) |
| Raport de contrast | 700:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193172% |
| timp de raspuns | 1.5/3.5 (Typ.)(Tr/Td) |
| unghi de vedere | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 4 stringsWLEDWithout Driver |
| interfață de semnal | LVDS (1 ch, 8-bit), 30 pins |
| tensiune de intrare | 5.0V (Typ.) |
| aplicarea | DMPC |
| LC185EXN-SDA1 | LG Display | 18.5 | 1366×768 |
| M185B1-L02 | Innolux | 18.5 | 1366×768 |
| M185B1-L07 | Innolux | 18.5 | 1366×768 |
| M185B3-LA1 | Innolux | 18.5 | 1366×768 |
| M185BGE-L10 | Innolux | 18.5 | 1366×768 |
| M185BGE-L22 | Innolux | 18.5 | 1366×768 |
| M185BGE-L23 | Innolux | 18.5 | 1366×768 |
| M185BGE-L2U | Innolux | 18.5 | 1366×768 |
| M185BGE-P02 | Innolux | 18.5 | 1366×768 |
| HM200WD1-100 | BOE | 20.0 | 1600×900 |
| HT15X23-100 | HYDIS | 15.0 | 1024×768 |
| LM200WD3-TLC7 | LG Display | 20.0 | 1600×900 |
| LM201WE3-TLF8 | LG Display | 20.1 | 1680×1050 |
| LM220WE1-TLP1 | LG Display | 22.0 | 1680×1050 |
| LM240WU8-SLA3 | LG Display | 24.0 | 1920×1200 |
| LM240WU8-SLD4 | LG Display | 24.0 | 1920×1200 |
| M170EG01 VD | AUO | 17.0 | 1280×1024 |
| MT190AW01 V.5 | Innolux | 19.0 | 1440×900 |
| NL10276AC30-07 | NLT | 15.0 | 1024×768 |
