| PartNumber | TX38D14VC0CAA |
| Marca | KOE |
| mărimea | 15.0 |
| Aplicație | DMPC |
| Rezoluţie | 1024×768 |
| Compoziţie | LCM |
| Luminozitate | 200 |
| CR | 300:1 |
| Culori | 16.7M |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | HITACHI |
| model de panou | TX38D14VC0CAA |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 15.0 inch |
| rezoluţie | 1024(RGB)×768 , XGA |
| modul de afișare | IPS, Normally Black, Transmissive |
| Zonă activă | 304.128×228.096 mm |
| contur | 350×265 mm |
| suprafaţă | |
| luminozitatea | 200 cd/m² (Typ.) |
| Raport de contrast | 300:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit) |
| timp de raspuns | 25/25 (Typ.)(Tr/Td) |
| unghi de vedere | 80/80/80/80 (Min.)(CR≥20)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 4 pcsCCFLWithout Driver |
| interfață de semnal | LVDS (1 ch, 8-bit), 20 pins |
| tensiune de intrare | 5.0V (Typ.) |
| aplicarea | DMPC |
