| PartNumber | LSL080AL02-B01 |
| Marca | Samsung |
| mărimea | 8.0 |
| Aplicație | PAD |
| Rezoluţie | 800×1280 |
| Compoziţie | LCM |
| Luminozitate | |
| CR | 800:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | Analog |
| marca panoului | SAMSUNG |
| model de panou | LSL080AL02-B01 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 8.0 inch |
| rezoluţie | 800(RGB)×1280 , WXGA |
| modul de afișare | PLS, Normally Black, Transmissive |
| Zonă activă | 107.64×172.224 mm |
| suprafaţă | Hard coating |
| luminozitatea | |
| Raport de contrast | 800:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193155% |
| timp de raspuns | 16 (Typ.)(Tr+Td) |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLED |
| aplicarea | PAD |
