| PartNumber | LQ065Y5DG01 |
| Marca | SHARP |
| mărimea | 6.5 |
| Aplicație | CNS |
| Rezoluţie | 800×480 |
| Compoziţie | LCM |
| Luminozitate | 380 |
| CR | 100:1 |
| Culori | 262K |
| Iluminare de fundal | CCFL |
| Interfață | TTL |
| marca panoului | SHARP |
| model de panou | LQ065Y5DG01 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 6.5 inch |
| rezoluţie | 800(RGB)×480 , WVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 144×78.24 mm |
| contur | 157.2×89.7 mm |
| suprafaţă | Antiglare |
| luminozitatea | 380 cd/m² (Typ.) |
| Raport de contrast | 100:1 (Min.) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | 30/50 (Typ.)(Tr/Td) |
| unghi de vedere | 65/65/60/65 (Typ.)(CR≥5)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 1 pcsCCFLWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 6-bit), 65 pins |
| tensiune de intrare | 5/3.3/15/-12/-14.4/-17.4V (Typ.)(VSHA/VGHD/VDD/VEE/VCC/VSS) |
| rohs: | |
| aplicarea | CNS |
