| PartNumber | LQ040Y3DX80B |
| Marca | SHARP |
| mărimea | 4.0 |
| Aplicație | HHP |
| Rezoluţie | 480×800 |
| Compoziţie | LCM |
| Luminozitate | 600 |
| CR | 650:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | SHARP |
| model de panou | LQ040Y3DX80B |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 4.0 inch |
| rezoluţie | 480(RGB)×800 , WVGA |
| modul de afișare | New Mode2, Normally Black, Transmissive |
| Zonă activă | 51.84×86.4 mm |
| contur | 57.14×96.85×2 mm |
| suprafaţă | |
| luminozitatea | 600 cd/m² (Typ.) |
| Raport de contrast | 650:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193170% |
| timp de raspuns | 35 (Typ.)(Tr+Td) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 8-bit) + SPI, 51 pins |
| tensiune de intrare | 2.8/1.8V (Typ.)(VCI/IOVCC) |
| aplicarea | HHP |
