| PartNumber | HV089WX1-100 |
| Marca | HYDIS |
| mărimea | 8.9 |
| Aplicație | PAD |
| Rezoluţie | 1280×768 |
| Compoziţie | LCM |
| Luminozitate | 300 |
| CR | 500:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | BOE HYDIS |
| model de panou | HV089WX1-100 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 8.9 inch |
| rezoluţie | 1280(RGB)×768 , WXGA |
| modul de afișare | AFFS, Normally Black, Transmissive |
| Zonă activă | 193.92×116.352 mm |
| contur | 224×133×5.25 mm |
| suprafaţă | |
| luminozitatea | 300 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Typ.) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | 28 (Typ.)(Tr+Td) |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 6S6PWLEDWithout Driver |
| interfață de semnal | LVDS (1 ch, 6-bit), 30 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | PAD |
| A089SW01 V0 | AUO | 8.9 | 1024×600 |
| B089AW01 V0 | AUO | 8.9 | 1024×600 |
| B089AW01 V2 | AUO | 8.9 | 1024×600 |
| B089AW01 V3 | AUO | 8.9 | 1024×600 |
| HV089WU1-1E0 | HYDIS | 8.9 | 1920×1200 |
| HV089WX1-100 | HYDIS | 8.9 | 1280×768 |
| LTL089CL02-W02 | Samsung | 8.9 | 1920×1200 |
| LTN089NT01 | Samsung | 8.9 | 1024×600 |
| N089L6-L03 | Innolux | 8.9 | 1024×600 |
| VVX09F035M20 | Panasonic | 8.9 | 1920×1200 |
| B101EAN01.2 | AUO | 10.1 | 1280×800 |
| B101UAN01.1 | AUO | 10.1 | 1920×1200 |
| B101UAN01.C | AUO | 10.1 | 1920×1200 |
| B116XAN03.1 HW0A | AUO | 11.6 | 1366×768 |
| BP070WSA-400 | BOE | 7.0 | 1024×600 |
| CLAA101WH12 LE | CPT | 10.1 | 1280×800 |
| LP094WX1-SLA2 | LG Display | 9.4 | 1280×800 |
| LTL101AL01-W01 | Samsung | 10.1 | 1280×800 |
| LTN097QL01-A02 | Samsung | 9.7 | 2048×1536 |
| Q070LRE-LB1 | Innolux | 7.0 | 1024×600 |
