| PartNumber | CM546B1-002 |
| Marca | CSOT |
| mărimea | 5.5 |
| Aplicație | MPH |
| Rezoluţie | 1080×1920 |
| Compoziţie | CELL |
| Luminozitate | 0 |
| CR | 1200:1 |
| Culori | |
| Iluminare de fundal | No B/L |
| Interfață | |
| marca panoului | CSOT |
| model de panou | CM546B1-002 |
| tip panou | a-Si TFT-LCD , CELL |
| dimensiunea panoului | 5.5 inch |
| rezoluţie | 1080(RGB)×1920 , FHD |
| modul de afișare | FFS, Normally Black, Transmissive |
| Zonă activă | 68.04×120.96 mm |
| contur | 69.64×127.19 mm |
| suprafaţă | With Polarizer |
| adâncimea sticlei | 0.15+0.15 mm |
| transmisivitatea | 4.81% (Typ.)(with APCF) |
| Raport de contrast | 1200:1 (Typ.) |
| culorile afișajului | , CIE193172% |
| timp de raspuns | 25 (Typ.)(Tr+Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| aplicarea | MPH |
