| PartNumber | CLAA035JA01CW |
| Marca | CPT |
| mărimea | 3.5 |
| Aplicație | |
| Rezoluţie | 144×480 |
| Compoziţie | LCM |
| Luminozitate | 300 |
| CR | 500:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | CPT |
| model de panou | CLAA035JA01CW |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 3.5 inch |
| rezoluţie | 144(RGB)×480 |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 25.92×86.4 mm |
| contur | 33.9×100.2 mm |
| suprafaţă | Antiglare |
| luminozitatea | 300 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193150% |
| timp de raspuns | 25 (Typ.)(Tr+Td) |
| unghi de vedere | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | 2S2PWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 6-bit) + SPI, 67 pins |
| tensiune de intrare | 2.8/2.8/2.8V (Typ.)(VCC/VCI/IOVCC) |
| rohs: |
