| PartNumber | BP070WX6-400 |
| Marca | BOE |
| mărimea | 7.0 |
| Aplicație | PAD |
| Rezoluţie | 800×1280 |
| Compoziţie | CELL |
| Luminozitate | 0 |
| CR | 850:1 |
| Culori | 16.7M |
| Iluminare de fundal | No B/L |
| Interfață | MIPI |
| marca panoului | BOE |
| model de panou | BP070WX6-400 |
| tip panou | a-Si TFT-LCD , CELL |
| dimensiunea panoului | 7.0 inch |
| rezoluţie | 800(RGB)×1280 , WXGA |
| modul de afișare | ADS, Normally Black, Transmissive |
| Zonă activă | 94.2×150.72 mm |
| contur | 98.7×159.93 mm |
| suprafaţă | Antiglare (Haze 25%) |
| adâncimea sticlei | 0.30+0.30 mm |
| transmisivitatea | 4.8% (Typ.)(with Polarizer) |
| Raport de contrast | 850:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193155% |
| timp de raspuns | 30 (Typ.)(Tr+Td) |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| driver ic | COG Built-in S6D7AA0 |
| aplicarea | PAD |
