| PartNumber | LD070WU2-SM01 |
| Marca | LG Display |
| mărimea | 7.0 |
| Aplicație | PAD |
| Rezoluţie | 1200×1920 |
| Compoziţie | LCM |
| Luminozitate | 450 |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | QLED |
| Interfață | MIPI |
| marca panoului | LG Display |
| model de panou | LD070WU2-SM01 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 7.0 inch |
| rezoluţie | 1200(RGB)×1920 , WUXGA |
| modul de afișare | IPS, Normally Black, Transmissive |
| Zonă activă | 94.5×151.2 mm |
| contur | 104.52×161.87×2.4 mm |
| suprafaţă | Hard coating |
| luminozitatea | 450 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193170% |
| timp de raspuns | 16 (Typ.)(Tr+Td) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 4S6PQLEDWithout Driver |
| interfață de semnal | MIPI (4 data lanes), 40 pins |
| tensiune de intrare | 3.7/1.8V (Typ.)(VSYS/VDD) |
| aplicarea | PAD |
