| PartNumber | YX035CM31 |
| Marca | |
| mărimea | 3.5 |
| Aplicație | HHP |
| Rezoluţie | 320×240 |
| Compoziţie | LCM |
| Luminozitate | 800 |
| CR | 400:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | Parallel/Serial |
| marca panoului | |
| model de panou | YX035CM31 1 Compatible model |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 3.5 inch |
| rezoluţie | 320(RGB)×240 , QVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 70.08×52.56 mm |
| contur | 76.9×63.9 mm |
| suprafaţă | Antiglare (Haze 20%) |
| luminozitatea | 800 cd/m² (Typ.) |
| Raport de contrast | 400:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit) |
| timp de raspuns | 10/15 (Typ.)(Tr/Td) |
| unghi de vedere | 60/60/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 5S2PWLEDWithout Driver |
| interfață de semnal | Digital RGB (8/24-bit) + SPI, CCIR601/656, 54 pins |
| tensiune de intrare | 3.3/13.9/13.6V (Typ.)(VCC/VGH/VGL) |
| aplicarea | HHP |
| 35QVW1T | SII | 3.5 | 320×240 |
| H347QVN02.0 | AUO | 3.5 | 320×480 |
| LMS350GF03-001 | Samsung | 3.5 | 320×240 |
| LTV350QV-F07 | Samsung | 3.5 | 320×240 |
| PD035QX1 | E Ink | 3.5 | 240×320 |
| PJ035MA-02A | Innolux | 3.5 | 320×480 |
| PT035TN23 V.3 | Innolux | 3.5 | 320×240 |
| TM035KBH02 | Tianma | 3.5 | 320×240 |
| TM035KDH03-79 | Tianma | 3.5 | 320×240 |
| YX035CM31 | 3.5 | 320×240 |
| 24QVW2H | SII | 2.4 | 240×320 |
| 35WVF0H | SII | 3.5 | 480×800 |
| AM-240320-022F | Other | 2.2 | 240×320 |
| COM35T3112DTR | ORTUSTECH | 3.5 | 240×320 |
| LQ043T1DG02 | SHARP | 4.3 | 480×272 |
| LQ043T1DG28 | SHARP | 4.3 | 480×272 |
| LS027B7DH01 | SHARP | 2.7 | 400×240 |
| TFTMD030011 | JDI | 3.0 | 720×480 |
| TM030LDHT2 | Tianma | 3.0 | 240×400 |
| TX09D200VM0BAA | KOE | 3.5 | 240×320 |
