| PartNumber | TX23D85VM0BAA |
| Marca | KOE |
| mărimea | 9.0 |
| Aplicație | IA |
| Rezoluţie | 1280×768 |
| Compoziţie | LCM |
| Luminozitate | |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | HITACHI |
| model de panou | TX23D85VM0BAA |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 9.0 inch |
| rezoluţie | 1280(RGB)×768 , WXGA |
| modul de afișare | IPS, Normally Black, Transmissive |
| Zonă activă | 193.92×116.352 mm |
| suprafaţă | |
| luminozitatea | |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit) |
| timp de raspuns | |
| unghi de vedere | 85/85/85/85 (Typ.)(CR＞10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | LVDS (1 ch, 8-bit) |
| aplicarea | IA |
