| PartNumber | TX20D28VM2BAB |
| Marca | KOE |
| mărimea | 8.0 |
| Aplicație | IA |
| Rezoluţie | 800×480 |
| Compoziţie | LCM |
| Luminozitate | 550 |
| CR | 600:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | HITACHI |
| model de panou | TX20D28VM2BAB |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 8.0 inch |
| rezoluţie | 800(RGB)×480 , WVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 174×104.4 mm |
| contur | 189×120 mm |
| suprafaţă | |
| luminozitatea | 550 cd/m² (Typ.) |
| Raport de contrast | 600:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193165% |
| timp de raspuns | 20/10 (Typ.)(Tr/Td) |
| unghi de vedere | 80/80/60/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 3S17PWLEDEmbedded (LED Driver) |
| interfață de semnal | LVDS (1 ch, 6-bit), 20 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | IA |
| A080SN03 V3 | AUO | 8.0 | 800×600 |
| BP080WX7-100 | BOE | 8.0 | 1280×800 |
| G080Y1-T01 | Innolux | 8.0 | 800×480 |
| LA080WV1-TD01 | LG Display | 8.0 | 800×480 |
| LA080WV2-TD01 | LG Display | 8.0 | 800×480 |
| LAJ080W001A | TPO | 8.0 | 800×480 |
| LQ080Y5DG03 | SHARP | 8.0 | 800×480 |
| LT080EE04100 | TOSHIBA | 8.0 | 1600×768 |
| TM080XPH01 | Tianma | 8.0 | 1280×768 |
| TX20D28VM2BAB | KOE | 8.0 | 800×480 |
| AA065VE11ADA11 | Mitsubishi | 6.5 | 640×480 |
| DLC0900DIG-1 | Other | 9.0 | 800×480 |
| DMF5005NYJ-LY | Kyocera | 5.2 | 240×64 |
| LM8M64 | SHARP | 8.1 | 640×240 |
| LT084AC27800 | TOSHIBA | 8.4 | 800×600 |
| LTD121C31S | TOSHIBA | 12.1 | 800×600 |
| M101GWN9 R0 | IVO | 10.1 | 1024×600 |
| M101GWN9 R2 | IVO | 10.1 | 1024×600 |
| NL10276BC24-19D | NLT | 12.1 | 1024×768 |
| TX14D12VM1CBA | KOE | 5.7 | 320×240 |
