| PartNumber | LQ080Y5DG03 |
| Marca | SHARP |
| mărimea | 8.0 |
| Aplicație | CNS |
| Rezoluţie | 800×480 |
| Compoziţie | LCM |
| Luminozitate | 540 |
| CR | |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | SHARP |
| model de panou | LQ080Y5DG03 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 8.0 inch |
| rezoluţie | 800(RGB)×480 , WVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 174×104.4 mm |
| contur | 190×120 mm |
| suprafaţă | |
| luminozitatea | 540 cd/m² (Typ.) |
| Raport de contrast | |
| culorile afișajului | 262K (6-bit), CIE193165% |
| timp de raspuns | |
| unghi de vedere | |
| tip lampa | WLED |
| interfață de semnal | Parallel RGB (1 ch, 6-bit) |
| aplicarea | CNS |
