| PartNumber | NL10276BC24-19D |
| Marca | NLT |
| mărimea | 12.1 |
| Aplicație | IA |
| Rezoluţie | 1024×768 |
| Compoziţie | LCM |
| Luminozitate | 650 |
| CR | 600:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | NEC |
| model de panou | NL10276BC24-19D |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 12.1 inch |
| rezoluţie | 1024(RGB)×768 , XGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 245.76×184.32 mm |
| contur | 260×200×7.4 mm |
| suprafaţă | Antiglare, Hard coating (3H) |
| luminozitatea | 650 cd/m² (Typ.) |
| Raport de contrast | 600:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193140% |
| timp de raspuns | 6/19 (Typ.)(Tr/Td) |
| unghi de vedere | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 9S5PWLEDWithout Driver |
| interfață de semnal | LVDS (1 ch, 6-bit), 30 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | IA |
| NL10276AC20-03 | NLT | 10.4 | 1024×768 |
| NL10276AC28-05R | NLT | 14.1 | 1024×768 |
| NL10276BC20-18 | NLT | 10.4 | 1024×768 |
| NL10276BC20-18F | NLT | 10.4 | 1024×768 |
| NL10276BC24-19D | NLT | 12.1 | 1024×768 |
| NL10276BC24-21 | NLT | 12.1 | 1024×768 |
| NL10276BC28-21A | NLT | 14.1 | 1024×768 |
| NL10276BC30-18L | NLT | 15.0 | 1024×768 |
| NL10276BC30-34D | NLT | 15.0 | 1024×768 |
| NL10276BC30-38B | NLT | 15.0 | 1024×768 |
| AA104VC10 | Mitsubishi | 10.4 | 640×480 |
| DLC1040ABG-2 | Other | 10.4 | 800×600 |
| G084SN02 V0 | AUO | 8.4 | 800×600 |
| G121SN01 V1 | AUO | 12.1 | 800×600 |
| LM065HB1T01 | SHARP | 6.5 | 640×240 |
| LQ104V1LG81 | SHARP | 10.4 | 640×480 |
| MC57T04L | Other | 5.7 | 320×240 |
| NL10276BC24-21 | NLT | 12.1 | 1024×768 |
| RX215-C10 | ROGIN | 21.5 | 1920×1080 |
| T78AAVGTF0 | Other | 5.7 | 320×240 |
