| PartNumber | NL10276AC20-03 |
| Marca | NLT |
| mărimea | 10.4 |
| Aplicație | IA |
| Rezoluţie | 1024×768 |
| Compoziţie | LCM |
| Luminozitate | 85 |
| CR | 100:1 |
| Culori | 4096 |
| Iluminare de fundal | CCFL |
| Interfață | TTL |
| marca panoului | NEC |
| model de panou | NL10276AC20-03 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 10.4 inch |
| rezoluţie | 1024(RGB)×768 , XGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 211.968×158.976 mm |
| contur | 282×190×13 mm |
| suprafaţă | |
| luminozitatea | 85 cd/m² (Typ.) |
| Raport de contrast | 100:1 (Typ.) |
| culorile afișajului | 4096 (4-bit), CIE193140% |
| timp de raspuns | 40 (Min.)(Tr+Td) |
| unghi de vedere | 45/45/25/25 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 1 pcsCCFLEmbedded (Inverter) |
| interfață de semnal | TTL (1 ch, 4-bit), 65 pins |
| tensiune de intrare | 5.0/12.0V (Typ.)(VCC/VDD) |
| aplicarea | IA |
