| PartNumber | TX18D35VM0AAA |
| Marca | KOE |
| mărimea | 7.0 |
| Aplicație | CNS |
| Rezoluţie | 800×480 |
| Compoziţie | LCM |
| Luminozitate | 450 |
| CR | 600:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | HITACHI |
| model de panou | TX18D35VM0AAA |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 7.0 inch |
| rezoluţie | 800(RGB)×480 , WVGA |
| modul de afișare | IPS Pro, Normally Black, Transmissive |
| Zonă activă | 152.4×91.44 mm |
| contur | 165×104×13.3 mm |
| suprafaţă | |
| luminozitatea | 450 cd/m² (Typ.) |
| Raport de contrast | 600:1 (Typ.) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | 45 (Max.)(Tr+Td) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 3S4PWLEDEmbedded (LED Driver) |
| interfață de semnal | CMOS (1 ch, 6-bit), 40 pins |
| tensiune de intrare | 3.3V (Typ.)(VDD) |
| aplicarea | CNS |
| BA070WS1-402 | BOE | 7.0 | 1024×600 |
| CLAA070JA1BCW | CPT | 7.0 | 480×234 |
| CLAA070NC0DCW | CPT | 7.0 | 1024×600 |
| LB070WV4-SD01 | LG Display | 7.0 | 800×480 |
| LTP700WV-F01 | Samsung | 7.0 | 800×480 |
| TM070WA-22L06 | SANYO | 7.0 | 480×234 |
| TX18D30VM2FAA | KOE | 7.0 | 800×480 |
| TX18D35VM0AAA | KOE | 7.0 | 800×480 |
| TX18D37VM0AQA | KOE | 7.0 | 800×480 |
| TX18D37VM0ARA | KOE | 7.0 | 800×480 |
| 70WVW1T | SII | 7.0 | 800×480 |
| C070FW02 V0 | AUO | 7.0 | 480×234 |
| C090EAN01.1 | AUO | 9.0 | 1280×720 |
| CLAA050JA01CT | CPT | 5.0 | 480×272 |
| CLAA070LD0DCW | CPT | 7.0 | 800×480 |
| L5F30614T65 | SANYO | 8.0 | 800×480 |
| LA070WV5-SL01 | LG Display | 7.0 | 800×480 |
| LB058WQ1-SD01 | LG Display | 5.8 | 400×240 |
| LQ065T5BR08 | SHARP | 6.5 | 400×240 |
| LTA061B2E0F | TOSHIBA | 6.1 |
