| PartNumber | TM062RDH03 |
| Marca | Tianma |
| mărimea | 6.2 |
| Aplicație | CNS |
| Rezoluţie | 800×480 |
| Compoziţie | LCM |
| Luminozitate | 400 |
| CR | 500:1 |
| Culori | 262K/16.7M |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | TIANMA |
| model de panou | TM062RDH03 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 6.2 inch |
| rezoluţie | 800(RGB)×480 , WVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 137.4×77.28 mm |
| contur | 155.2×88.2×5.2 mm |
| suprafaţă | Antiglare |
| luminozitatea | 400 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Typ.) |
| culorile afișajului | 262K/16.7M (6-bit / 6-bit + Dithering), CIE193147% |
| timp de raspuns | 20 (Typ.)(Tr+Td) |
| unghi de vedere | 75/75/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | 3S8PWLEDWithout Driver |
| interfață de semnal | TTL (1 ch, 8-bit), 60 pins |
| tensiune de intrare | 3.3/9.84/19/-7V (Typ.)(AVCC/DVCC/VGH/VGL) |
| aplicarea | CNS |
