| PartNumber | HSD062IDW1-A00 |
| Marca | HannStar |
| mărimea | 6.2 |
| Aplicație | CNS |
| Rezoluţie | 800×480 |
| Compoziţie | LCM |
| Luminozitate | 400 |
| CR | 600:1 |
| Culori | 262K/16.2M |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | HannStar |
| model de panou | HSD062IDW1-A00 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 6.2 inch |
| rezoluţie | 800(RGB)×480 , WVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 137.52×77.232 mm |
| contur | 155.2×88.2×5.3 mm |
| suprafaţă | Antiglare, Hard coating (3H) |
| luminozitatea | 400 cd/m² (Typ.) |
| Raport de contrast | 600:1 (Typ.) |
| culorile afișajului | 262K/16.2M (6-bit / 6-bit + FRC), CIE193150% |
| timp de raspuns | 2/6 (Typ.)(Tr/Td) |
| unghi de vedere | 75/75/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 3S7PWLEDWithout Driver |
| interfață de semnal | TTL (1 ch, 6/8-bit), 60 pins |
| tensiune de intrare | 3.3/10.0/15.0/-7.0V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplicarea | CNS |
| C070VW01 V0 | AUO | 7.0 | 800×480 |
| LA070WV6-SD01 | LG Display | 7.0 | 800×480 |
| LAJ084T001A | TPO | 8.4 | 800×600 |
| LB070WV7-TD02 | LG Display | 7.0 | 800×480 |
| LQ042T5DZ01 | SHARP | 4.2 | 480×272 |
| LQ042T5DZ01A | SHARP | 4.2 | 480×272 |
| LQ070Y5DA02A | SHARP | 7.0 | 800×480 |
| LQ080Y5DW03 | SHARP | 8.0 | 800×480 |
| LTA070B052F | TOSHIBA | 7.0 | 800×480 |
| PA050XS7 | E Ink | 5.0 | 320×234 |
