| PartNumber | TM030LDHT1 |
| Marca | Tianma |
| mărimea | 3.0 |
| Aplicație | HHP |
| Rezoluţie | 240×400 |
| Compoziţie | LCM |
| Luminozitate | 130 |
| CR | 100:1 |
| Culori | 65K/262K |
| Iluminare de fundal | WLED |
| Interfață | CPU/RGB/SPI |
| marca panoului | TIANMA |
| model de panou | TM030LDHT1 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 3.0 inch |
| rezoluţie | 240(RGB)×400 , WQVGA |
| modul de afișare | ECB, Normally White, Transflective |
| Zonă activă | 38.88×64.8 mm |
| contur | 47.28×76.4 mm |
| suprafaţă | Clear, Hard coating (3H) |
| luminozitatea | 130 cd/m² (Typ.) |
| Raport de contrast | 100:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| culorile afișajului | 65K/262K , CIE193134% |
| timp de raspuns | 35 (Typ.)(Tr+Td) |
| unghi de vedere | 40/45/55/40 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 4S1PWLEDWithout Driver |
| interfață de semnal | CPU/RGB/SPI, 45 pins |
| tensiune de intrare | 2.8/2.8V (Typ.)(IOVCC/VCC) |
| aplicarea | HHP |
