| PartNumber | TD070WGCB1 |
| Marca | TPO |
| mărimea | 7.0 |
| Aplicație | CNS |
| Rezoluţie | 854×480 |
| Compoziţie | LCM |
| Luminozitate | 420 |
| CR | 150:1 |
| Culori | 262K |
| Iluminare de fundal | CCFL |
| Interfață | TTL |
| marca panoului | Toppoly |
| model de panou | TD070WGCB1 |
| tip panou | LTPS TFT-LCD , LCM |
| dimensiunea panoului | 7.0 inch |
| rezoluţie | 854(RGB)×480 , FWVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 155×87.12 mm |
| contur | 166.4×106.3×8.9 mm |
| suprafaţă | |
| luminozitatea | 420 cd/m² (Typ.) |
| Raport de contrast | 150:1 (Typ.) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | 7/18 (Typ.)(Tr/Td) |
| unghi de vedere | 75/75/60/80 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | 2 pcsCCFLWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 6-bit), 40 pins |
| tensiune de intrare | 3.3V (Typ.)(VDD) |
| aplicarea | CNS |
