| PartNumber | SVA190WX05TB |
| Marca | SVA-NEC |
| mărimea | 19.0 |
| Aplicație | DMPC |
| Rezoluţie | 1440×900 |
| Compoziţie | LCM |
| Luminozitate | 300 |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | SVA-NEC |
| model de panou | SVA190WX05TB |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 19.0 inch |
| rezoluţie | 1440(RGB)×900 , WXGA+ |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 408.24×255.15 mm |
| contur | 428×278 mm |
| suprafaţă | Antiglare, Hard coating (3H) |
| luminozitatea | 300 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 16.7M (6-bit + Hi-FRC), CIE193172% |
| timp de raspuns | |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 4 pcsCCFL |
| interfață de semnal | LVDS (2 ch, 8-bit) |
| rohs: | |
| aplicarea | DMPC |
| HSD190MEN6-A00 | HannStar | 19.0 | 1280×1024 |
| HSD190MGW1-B00 | HannStar | 19.0 | 1440×900 |
| LM190E03-TLB4 | LG Display | 19.0 | 1280×1024 |
| LM190E05-SL03 | LG Display | 19.0 | 1280×1024 |
| LM190E08-TLL3 | LG Display | 19.0 | 1280×1024 |
| LTB190E3-L01 | Samsung | 19.0 | 1280×1024 |
| LTM190EX-L21 | Samsung | 19.0 | 1280×1024 |
| M190A1-L01 | Innolux | 19.0 | 1440×900 |
| SVA190WX01TB | SVA-NEC | 19.0 | 1440×900 |
| SVA190WX05TB | SVA-NEC | 19.0 | 1440×900 |
| HT17E12-210 | HYDIS | 17.0 | 1280×1024 |
| LM300W01-STA1 | LG Display | 30.0 | 2560×1600 |
| LTM170E8-L02 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-L31 | Samsung | 17.0 | 1280×1024 |
| LTM200KT01 | Samsung | 20.0 | 1600×900 |
| M220ZGE-L20 | Innolux | 22.0 | 1680×1050 |
| M240HTN01.1 | AUO | 24.0 | 1920×1080 |
| MT190AW02 V.Y | Innolux | 19.0 | 1440×900 |
| TM190MDS01 | Tianma | 19.0 | 1440×900 |
| TMS156WX1-02TC | Tianma | 15.6 | 1366×768 |
