| PartNumber | R213T3-L02 |
| Marca | Innolux |
| mărimea | 21.3 |
| Aplicație | MD |
| Rezoluţie | 2560×2048 |
| Compoziţie | LCM |
| Luminozitate | |
| CR | 850:1 |
| Culori | Grayscale |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | CMO |
| model de panou | R213T3-L02 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 21.3 inch |
| rezoluţie | 2560(LCR)×2048 , QSXGA |
| modul de afișare | DD-IPS, Normally Black, Transmissive |
| Zonă activă | 422.4×337.92 mm |
| contur | 459.8×375.3 mm |
| suprafaţă | |
| luminozitatea | |
| Raport de contrast | 850:1 (Typ.) |
| culorile afișajului | Grayscale (8-bit) |
| timp de raspuns | 18/18 (Typ.)(Tr/Td) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥20)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | CCFLEmbedded (Inverter) |
| interfață de semnal | LVDS (4 ch, 8-bit), 73 pins |
| tensiune de intrare | 12.0V (Typ.) |
| aplicarea | MD |
