R190EFE-L51

R190EFE-L51
R190EFE-L51
R190EFE-L51 thumb R190EFE-L51 thumb
Marca
Innolux
mărimea
19.0
Aplicație
MD
Rezoluţie
1280×1024
Compoziţie
LCM
Luminozitate
1400
CR
1000:1
Culori
Grayscale
Iluminare de fundal
WLED
Interfață
LVDS
In Stock
203
Specificații

PartNumber R190EFE-L51
MarcaInnolux
mărimea19.0
AplicațieMD
Rezoluţie1280×1024
CompoziţieLCM
Luminozitate1400
CR1000:1
CuloriGrayscale
Iluminare de fundalWLED
InterfațăLVDS
marca panouluiINNOLUX
model de panouR190EFE-L51
tip panou a-Si TFT-LCD , LCM
dimensiunea panoului19.0 inch
rezoluţie1280(LCR)×1024 , SXGA
modul de afișareDD-IPS, Normally Black, Transmissive
Zonă activă376.32×301.06 mm
contur396×324×26.1 mm
suprafaţăAntiglare (Haze 25%), Hard coating (3H)
luminozitatea1400 cd/m² (Typ.)
Raport de contrast1000:1 (Typ.)
culorile afișajuluiGrayscale (8-bit)
timp de raspuns15/15 (Typ.)(Tr/Td)
unghi de vedere85/85/85/85 (Typ.)(CR≥10)(L/R/U/D)
frecvență60Hz
tip lampa4 stringsWLEDEmbedded (LED Driver)
interfață de semnalLVDS (2 ch, 8-bit), 30 pins
tensiune de intrare12.0V (Typ.)
aplicareaMD
