| PartNumber | R300SFE-L02 |
| Marca | Innolux |
| mărimea | 30.0 |
| Aplicație | MD |
| Rezoluţie | 3280×2048 |
| Compoziţie | LCM |
| Luminozitate | 800 |
| CR | 1000:1 |
| Culori | 1.07B |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | INNOLUX |
| model de panou | R300SFE-L02 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 30.0 inch |
| rezoluţie | 3280(RGB)×2048 |
| modul de afișare | IPS, Normally Black, Transmissive |
| Zonă activă | 645.5×403.05 mm |
| contur | 678×448×30.5 mm |
| suprafaţă | Antiglare, Hard coating (3H) |
| luminozitatea | 800 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 1.07B (10-bit), CIE193169% |
| timp de raspuns | 15/15 (Typ.)(Tr/Td) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | LVDS (8 ch, 10-bit) |
| tensiune de intrare | 12.0V (Typ.) |
| aplicarea | MD |
