| PartNumber | R300M1-L01 |
| Marca | Innolux |
| mărimea | 30.0 |
| Aplicație | MD |
| Rezoluţie | 4096×2560 |
| Compoziţie | LCM |
| Luminozitate | 1200 |
| CR | 800:1 |
| Culori | Grayscale |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | CMO |
| model de panou | R300M1-L01 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 30.0 inch |
| rezoluţie | 4096(LCR)×2560 , DQSXGA |
| modul de afișare | IPS, Normally Black, Transmissive |
| Zonă activă | 645.12×403.2 mm |
| contur | 678×448×49.5 mm |
| suprafaţă | Antiglare (Haze 40%), Hard coating (3H) |
| luminozitatea | 1200 cd/m² (Typ.) |
| Raport de contrast | 800:1 (Min.) |
| culorile afișajului | Grayscale (10-bit) |
| timp de raspuns | 50/15 (Typ.)(Tr/Td) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥20)(L/R/U/D) |
| frecvență | 50Hz |
| tip lampa | CCFLEmbedded (Inverter) |
| interfață de semnal | LVDS (4 ch, 10-bit), 82 pins |
| tensiune de intrare | 12.0V (Typ.) |
| aplicarea | MD |
