| PartNumber | NL160120AC27-37 |
| Marca | NLT |
| mărimea | 21.3 |
| Aplicație | MD |
| Rezoluţie | 1600×1200 |
| Compoziţie | LCM |
| Luminozitate | 900 |
| CR | 1400:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | NLT |
| model de panou | NL160120AC27-37 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 21.3 inch |
| rezoluţie | 1600(RGB)×1200 , UXGA |
| modul de afișare | SFT, Normally Black, Transmissive |
| Zonă activă | 432×324 mm |
| contur | 457×350×22 mm |
| suprafaţă | Antiglare, Hard coating (2H) |
| luminozitatea | 900 cd/m² (Typ.) |
| Raport de contrast | 1400:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193172% |
| timp de raspuns | 20/20 (Typ.)(Tr/Td) |
| unghi de vedere | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | LVDS (2 ch, 8-bit), 30 pins |
| tensiune de intrare | 12.0V (Typ.) |
| aplicarea | MD |
| G213QAN01.0 | AUO | 21.3 | 2048×1536 |
| NL160120AC27-32B | NLT | 21.3 | 1600×1200 |
| NL160120BM27-03A | NLT | 21.3 | 1600×1200 |
| NL204153BM21-04A | NLT | 21.3 | 2048×1536 |
| R190E5-L01 | Innolux | 19.0 | 1280×1024 |
| R190E6-L01 | Innolux | 19.0 | 1280×1024 |
| R190EFE-L61 | Innolux | 19.0 | 1280×1024 |
| R208R3-L01 | Innolux | 20.8 | 2048×1536 |
| R213T3-L01 | Innolux | 21.3 | 2560×2048 |
| R213T3-L02 | Innolux | 21.3 | 2560×2048 |
