| PartNumber | LAM170M023A |
| Marca | JDI |
| mărimea | 17.0 |
| Aplicație | MD |
| Rezoluţie | 1280×1024 |
| Compoziţie | LCM |
| Luminozitate | 240 |
| CR | 900:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | JDI |
| model de panou | LAM170M023A |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 17.0 inch |
| rezoluţie | 1280(RGB)×1024 , SXGA |
| modul de afișare | IPS, Normally Black, Transmissive |
| Zonă activă | 337.92×270.336 mm |
| contur | 368×306×20.4 mm |
| suprafaţă | Antiglare, Hard coating (2H) |
| luminozitatea | 240 cd/m² (Typ.) |
| Raport de contrast | 900:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193174% |
| timp de raspuns | 10/12 (Typ.)(Tr/Td) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 3 stringsWLEDEmbedded (LED Driver) |
| interfață de semnal | LVDS (2 ch, 8-bit), 30 pins |
| tensiune de intrare | 5.0V (Typ.) |
| aplicarea | MD |
| G170ETN02.0 | AUO | 17.0 | 1280×1024 |
| L170E3 EC-5 | AUO | 17.0 | 1280×1024 |
| LAM170M023A | JDI | 17.0 | 1280×1024 |
| LM170E03-TLJ6 | LG Display | 17.0 | 1280×1024 |
| LTM170EU-L31 | Samsung | 17.0 | 1280×1024 |
| LTN170BT11-D03 | Samsung | 17.0 | 1440×900 |
| LTN170U1-L02 | Samsung | 17.0 | 1920×1200 |
| M170EG01 V5 | AUO | 17.0 | 1280×1024 |
| M170EG01 VH | AUO | 17.0 | 1280×1024 |
| M170XW01 V3 | AUO | 17.0 | 1280×768 |
| G213QAN01.0 | AUO | 21.3 | 2048×1536 |
| HV208QX1-100 | HYDIS | 20.8 | 2048×1536 |
| LAM170M023A | JDI | 17.0 | 1280×1024 |
| LB190E01-SL01 | LG Display | 19.0 | 1280×1024 |
| NL128102BM29-05A | NLT | 19.0 | 1280×1024 |
| NL160120BM27-03A | NLT | 21.3 | 1600×1200 |
| NL204153AC21-09 | NLT | 21.3 | 2048×1536 |
| NL204153BM21-05A | NLT | 21.3 | 2048×1536 |
| R300M1-L01 | Innolux | 30.0 | 4096×2560 |
| VVX21F136J00 | Panasonic | 21.3 | 1600×1200 |
