| PartNumber | LQ056A3AG01R |
| Marca | SHARP |
| mărimea | 5.6 |
| Aplicație | |
| Rezoluţie | 320×234 |
| Compoziţie | LCM |
| Luminozitate | 250 |
| CR | 60:1 |
| Culori | Full color |
| Iluminare de fundal | CCFL |
| Interfață | Analog |
| marca panoului | SHARP |
| model de panou | LQ056A3AG01R |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 5.6 inch |
| rezoluţie | 320(RGB)×234 |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 114.2×83.5 mm |
| contur | 140×102.7 mm |
| suprafaţă | |
| luminozitatea | 250 cd/m² (Typ.) |
| Raport de contrast | 60:1 (Typ.) |
| culorile afișajului | Full color |
| timp de raspuns | 15/20 (Typ.)(Tr/Td) |
| unghi de vedere | 65/65/40/65 (Typ.)(CR≥5)(L/R/U/D) |
| tip lampa | 1 pcsCCFLEmbedded (Inverter) |
| interfață de semnal | Analog RGB + Composite Video (NTSC/PAL), 24 pins |
| tensiune de intrare | 12.0V (Typ.) |
