| PartNumber | AT056TN52 V.5 |
| Marca | Innolux |
| mărimea | 5.6 |
| Aplicație | |
| Rezoluţie | 640×480 |
| Compoziţie | LCM |
| Luminozitate | 280 |
| CR | 500:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | INNOLUX |
| model de panou | AT056TN52 V.5 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 5.6 inch |
| rezoluţie | 640(RGB)×480 , VGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 112.896×84.672 mm |
| contur | 126.5×100×8.6 mm |
| suprafaţă | Hard coating (3H) |
| luminozitatea | 280 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193150% |
| timp de raspuns | 10/15 (Typ.)(Tr/Td) |
| unghi de vedere | 60/60/45/60 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | Parallel RGB (1 ch, 8-bit) + SPI, 40 pins |
| tensiune de intrare | 3.3V (Typ.) |
