| PartNumber | TD043MTEA1 |
| Marca | TPO |
| mărimea | 4.3 |
| Aplicație | |
| Rezoluţie | 800×480 |
| Compoziţie | LCM |
| Luminozitate | 300 |
| CR | 400:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | TPO |
| model de panou | TD043MTEA1 |
| tip panou | LTPS TFT-LCD , LCM |
| dimensiunea panoului | 4.3 inch |
| rezoluţie | 800(RGB)×480 , WVGA |
| modul de afișare | Normally Black, Transmissive |
| Zonă activă | 93.6×56.16 mm |
| contur | 100.6×68.45 mm |
| suprafaţă | |
| luminozitatea | 300 cd/m² (Typ.) |
| Raport de contrast | 400:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit) |
| timp de raspuns | 30 (Typ.)(Tr+Td) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 8S1PWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 8-bit), 60 pins |
| tensiune de intrare | 3.3/5.0/-5V (Typ.)(VCC/VDDP/VDDN) |
