| PartNumber | H572DAN01.2 |
| Marca | AUO |
| mărimea | 5.7 |
| Aplicație | MPH |
| Rezoluţie | 1080×1920 |
| Compoziţie | CELL |
| Luminozitate | 0 |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | No B/L |
| Interfață | MIPI |
| marca panoului | AUO |
| model de panou | H572DAN01.2 |
| tip panou | LTPS TFT-LCD , CELL |
| dimensiunea panoului | 5.7 inch |
| rezoluţie | 1080(RGB)×1920 , FHD |
| modul de afișare | AHVA, Normally Black, Transmissive |
| Zonă activă | 71.28×126.72 mm |
| contur | 73.68×133.27 mm |
| suprafaţă | Hard coating |
| adâncimea sticlei | 0.15+0.15 mm |
| transmisivitatea | 4.8% (Typ.)(with Polarizer) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193172% |
| timp de raspuns | 20/15 (Typ.)(Tr/Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥100)(L/R/U/D) |
| driver ic | COG Built-in R63311 |
| aplicarea | MPH |
