| PartNumber | KCS057QV1AJ-G20 |
| Marca | Kyocera |
| mărimea | 5.7 |
| Aplicație | IA |
| Rezoluţie | 320×240 |
| Compoziţie | LCM |
| Luminozitate | 200 |
| CR | 40:1 |
| Culori | Color |
| Iluminare de fundal | CCFL |
| Interfață | Parallel Data |
| marca panoului | Kyocera |
| model de panou | KCS057QV1AJ-G20 |
| tip panou | CSTN-LCD , LCM |
| dimensiunea panoului | 5.7 inch |
| rezoluţie | 320(RGB)×240 , QVGA |
| modul de afișare | STN, Normally Black, Transmissive |
| Zonă activă | 115.2×86.4 mm |
| contur | 154.6×114.8×9 mm |
| suprafaţă | Glare (Haze 0%) |
| luminozitatea | 200 cd/m² (Typ.) |
| Raport de contrast | 40:1 (Typ.) |
| culorile afișajului | Color |
| timp de raspuns | 220/110 (Typ.)(Tr/Td) |
| unghi de vedere | 50/50/30/30 (Typ.)(CR≥2)(L/R/U/D) |
| frecvență | 75Hz |
| tip lampa | 1 pcsCCFLOptional |
| interfață de semnal | Parallel Data (8-bit), 15 pins |
| tensiune de intrare | 5.0V (Typ.) |
| aplicarea | IA |
