| PartNumber | G170J1-LE1 |
| Marca | Innolux |
| mărimea | 17.0 |
| Aplicație | IA |
| Rezoluţie | 1920×1200 |
| Compoziţie | LCM |
| Luminozitate | 600 |
| CR | 2000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | INNOLUX |
| model de panou | G170J1-LE1 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 17.0 inch |
| rezoluţie | 1920(RGB)×1200 , WUXGA |
| modul de afișare | Super MVA, Normally Black, Transmissive |
| Zonă activă | 365.76×228.6 mm |
| contur | 386.8×250.8×19 mm |
| suprafaţă | Glare (Haze 0%) |
| luminozitatea | 600 cd/m² (Typ.) |
| Raport de contrast | 2000:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193170% |
| timp de raspuns | 20/9 (Typ.)(Tr/Td) |
| unghi de vedere | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | LVDS (2 ch, 8-bit), 30 pins |
| tensiune de intrare | 5.0V (Typ.) |
| aplicarea | IA |
