| PartNumber | RX024A-03 |
| Marca | ROGIN |
| mărimea | 2.4 |
| Aplicație | IA |
| Rezoluţie | 480×234 |
| Compoziţie | LCM |
| Luminozitate | 200 |
| CR | 400:1 |
| Culori | |
| Iluminare de fundal | WLED |
| Interfață | Serial RGB |
| marca panoului | ROGIN |
| model de panou | RX024A-03 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 2.4 inch |
| rezoluţie | 480×234 |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 48×35.685 mm |
| contur | 54.8×47.15×2.9 mm |
| suprafaţă | |
| luminozitatea | 200 cd/m² (Typ.) |
| Raport de contrast | 400:1 (Typ.) |
| culorile afișajului | , CIE193145% |
| timp de raspuns | 30 (Typ.)(Tr+Td) |
| unghi de vedere | 65/65/50/65 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | 2 pcsWLEDWithout Driver |
| interfață de semnal | Serial RGB (8-bit) + SPI, 40 pins |
| tensiune de intrare | 3.3/3.3V (Typ.)(VCC/IOVCC) |
| aplicarea | IA |
| 24QVF1H | SII | 2.4 | 240×320 |
| 24QVF1J | SII | 2.4 | 240×320 |
| 24QVF2H | SII | 2.4 | 240×320 |
| 24QVW1H | SII | 2.4 | 240×320 |
| ACM019A | Other | 2.4 | 128×64 |
| AM-240320-024DT | Other | 2.4 | 240×320 |
| FX020410DNSWBG01 | Data Image | 2.4 | 480×234 |
| LS024Q3UX12(G) | SHARP | 2.4 | 320×240 |
| RX024A-03 | ROGIN | 2.4 | 480×234 |
| UG-2864ASYPG01 | WiseChip | 2.4 | 128×64 |
| AA070ME01-DA1 | Mitsubishi | 7.0 | 800×480 |
| DLF1095 | LiteMax | 10.4 | 1024×768 |
| G104V1-T03 | Innolux | 10.4 | 640×480 |
| G150XG03 V0 | AUO | 15.0 | 1024×768 |
| LQ130V3FZ20G | SHARP | 13.0 | 640×480 |
| M150GNN2 R1 | IVO | 15.0 | 1024×768 |
| NL10276BC30-38B | NLT | 15.0 | 1024×768 |
| NL6448AC30-10 | NLT | 9.4 | 640×480 |
| OEL9M0065-Y-E | Other | 2.7 | 256×64 |
| UG-5664ALBDF01 | WiseChip | 2.8 | 256×64 |
