| PartNumber | CM546B2-001 |
| Marca | CSOT |
| mărimea | 5.5 |
| Aplicație | Mobile Phone |
| Rezoluţie | 1080×1920 |
| Compoziţie | LTPS TFT-LCD, CELL |
| Luminozitate | |
| CR | 1500:1 |
| Culori | 16.7M |
| Iluminare de fundal | No |
| Interfață | |
| marca panoului | CSOT |
| model de panou | CM546B2-001 |
| dimensiunea panoului | 5.5" |
| tip panou | LTPS TFT-LCD, CELL |
| rezoluţie | 1080(RGB)×1920, FHD, 403PPI |
| format de pixeli | RGB Vertical Stripe |
| zona de afisare | 68.04(W)×120.96(H) mm |
| deschiderea ramei | - |
| dimensiunea conturului | 69.44(W)×126.81(H) ×0.45(D) mm |
| suprafaţă | With Polarizer |
| luminozitatea | 0 cd/m² |
| Raport de contrast | 1500:1 (Typ.) (TM) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10) |
| modul de afișare | FFS, Normally Black, Transmissive |
| cea mai bună vedere pe | Symmetry |
| timp de raspuns | 35 (Typ.)(Tr+Td) |
| adâncimea sticlei | 0.15+0.15 mm |
| transmisivitatea | 4.69% (Typ.)(with APCF) |
| culorile afișajului | 16.7M 80% NTSC |
| tip lampa | No B/L |
| frecvență | - |
| touch screen | In-Cell Touch |
| driver ic | COG Built-in TD4310 |
| greutatea panoului | TBD |
| aplicarea | Mobile Phone |
| mediu inconjurator | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| CM546B1-002 | CSOT | 5.5 | 1080×1920 |
| E555HBM2 | EDO | 5.5 | 720×1280 |
| LH550WF1-SD01 | LG Display | 5.5 | 1080×1920 |
| LM6Q35 | SHARP | 5.5 | 320×240 |
| LS055R1SC01 | SHARP | 5.5 | 1440×2560 |
| NL3224AC35-01 | NLT | 5.5 | 320×240 |
| NL3224AC35-10 | NLT | 5.5 | 320×240 |
| NL3224BC35-20 | NLT | 5.5 | 320×240 |
| NL3224BC35-22 | NLT | 5.5 | 320×240 |
| TM055JDHP71 | Tianma | 5.5 | 720×1280 |
