| PartNumber | E555HBM2 |
| Marca | EDO |
| mărimea | 5.5 |
| Aplicație | MPH |
| Rezoluţie | 720×1280 |
| Compoziţie | OLED |
| Luminozitate | 300 |
| CR | 3000:1 |
| Culori | 16.7M |
| Iluminare de fundal | self |
| Interfață | MIPI |
| marca panoului | EDO |
| model de panou | E555HBM2 |
| tip panou | AM-OLED , OLED |
| dimensiunea panoului | 5.5 inch |
| rezoluţie | 720(RGB)×1280 , WXGA |
| Zonă activă | 69.12×122.88 mm |
| contur | 72.8×131.2 mm |
| suprafaţă | |
| luminozitatea | 300 cd/m² (Typ.) |
| Raport de contrast | 3000 : 1 (Min.) |
| culorile afișajului | 16.7M (8-bit), CIE1931105% |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥200)(L/R/U/D) |
| driver ic | COG Built-in SH1386 |
| interfață de semnal | MIPI (4 data lanes), 30 pins |
| tensiune de intrare | 3.3/4.6/6.1/-3.5V (Typ.)(VCI/VELVDD/VSP/VELVSS) |
| aplicarea | MPH |
