| PartNumber | CLAA080LG02AW |
| Marca | CPT |
| mărimea | 8.0 |
| Aplicație | CNS |
| Rezoluţie | 800×480 |
| Compoziţie | LCM |
| Luminozitate | 550 |
| CR | 700:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | CPT |
| model de panou | CLAA080LG02AW |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 8.0 inch |
| rezoluţie | 800(RGB)×480 , WVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 175.2×105.12 mm |
| contur | 186.5×117.22×6.73 mm |
| suprafaţă | Antiglare, Hard coating (3H) |
| luminozitatea | 550 cd/m² (Typ.) |
| Raport de contrast | 700:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193171% |
| timp de raspuns | 12 (Typ.)(Tr+Td) |
| unghi de vedere | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 9S4PWLEDWithout Driver |
| interfață de semnal | TTL (1 ch, 6-bit), 60 pins |
| tensiune de intrare | 3.3/12.0/18.0/-6.0V (Typ.)(VCC/VDDA/VGH/VGL) |
| aplicarea | CNS |
