| PartNumber | CLAA080LG01CW |
| Marca | CPT |
| mărimea | 8.0 |
| Aplicație | CNS |
| Rezoluţie | 800×480 |
| Compoziţie | LCM |
| Luminozitate | 750 |
| CR | 400:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | CPT |
| model de panou | CLAA080LG01CW |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 8.0 inch |
| rezoluţie | 800(RGB)×480 , WVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 175.2×105.12 mm |
| contur | 186.5×117.2×6.43 mm |
| suprafaţă | Antiglare, Hard coating (3H) |
| luminozitatea | 750 cd/m² (Typ.) |
| Raport de contrast | 400:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193171% |
| timp de raspuns | 20 (Typ.)(Tr+Td) |
| unghi de vedere | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 11S2PWLEDWithout Driver |
| interfață de semnal | TTL (1 ch, 6-bit), 60 pins |
| tensiune de intrare | 3.3/12.0/18.0/-6.0V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplicarea | CNS |
| CLAA080LB0AXV | CPT | 8.0 | 800×480 |
| CLAA080LG01CW | CPT | 8.0 | 800×480 |
| CLAA080LJ01CW | CPT | 8.0 | 800×480 |
| CLAA080NA12 CW | CPT | 8.0 | 1024×600 |
| CLAA080UA01 | CPT | 8.0 | 1600×768 |
| CLAA080WQ02 XG | CPT | 8.0 | 800×1280 |
| CLAA080WQ08 XN | CPT | 8.0 | 800×1280 |
| CLAA080XA03BW | CPT | 8.0 | 1024×768 |
| CLAA089NA0BCW | CPT | 8.9 | 1024×600 |
| CLAA089NA0FCW | CPT | 8.9 | 1024×600 |
| AM-800480STMQW-00 | AMPIRE | 7.0 | 800×480 |
| C065GW03 V0 | AUO | 6.5 | 400×240 |
| CLAA070LH01AW | CPT | 7.0 | 800×480 |
| G141I1-L01 | Innolux | 14.1 | 1280×800 |
| G150X1-L02 | Innolux | 15.0 | 1024×768 |
| LB043WQ4-TD01 | LG Display | 4.3 | 480×272 |
| LQ065T5GA01 | SHARP | 6.5 | 400×234 |
| LQ080Y5CGQ1 | SHARP | 8.0 | 800×480 |
| PW062XU7 | E Ink | 6.2 | 480×234 |
| PW080XU4 | E Ink | 8.0 | 480×220 |
