AT070TNA2 V.1

AT070TNA2 V.1
AT070TNA2 V.1
AT070TNA2 V.1 thumb AT070TNA2 V.1 thumb
Marca
Innolux
mărimea
7.0
Aplicație
MP4
Rezoluţie
1024×600
Compoziţie
LCM
Luminozitate
250
CR
700:1
Culori
262K/16.7M
Iluminare de fundal
WLED
Interfață
LVDS
In Stock
1000
Specificații

PartNumber AT070TNA2 V.1
MarcaInnolux
mărimea7.0
AplicațieMP4
Rezoluţie1024×600
CompoziţieLCM
Luminozitate250
CR700:1
Culori262K/16.7M
Iluminare de fundalWLED
InterfațăLVDS
marca panouluiCHIMEI INNOLUX
model de panouAT070TNA2 V.1 4 Compatible model
tip panou a-Si TFT-LCD , LCM
dimensiunea panoului7.0 inch
rezoluţie1024(RGB)×600 , WSVGA
modul de afișareTN, Normally White, Transmissive
Zonă activă153.6×90 mm
contur165.75×105.39×3.7 mm
suprafaţăGlare (Haze 0%), Hard coating
luminozitatea250 cd/m² (Typ.)
Raport de contrast700:1 (Typ.)
culorile afișajului262K/16.7M (6-bit / 6-bit + Dithering)
timp de raspuns10/15 (Typ.)(Tr/Td)
unghi de vedere75/75/70/75 (Typ.)(CR≥10)(L/R/U/D)
frecvență60Hz
tip lampa3S6PWLEDWithout Driver
interfață de semnalLVDS (1 ch, 6/8-bit), 40 pins
tensiune de intrare3.3/11.0/20.0/-6.8V (Typ.)(VDD/AVDD/VGH/VGL)
aplicareaMP4
Model de familie
AT070TN07 V.A Innolux 7.0 480×234
AT070TN82 Innolux 7.0 800×480
AT070TN82 V.1 Innolux 7.0 800×480
AT070TN83 V.3 Innolux 7.0 800×480
AT070TN84 Innolux 7.0 800×480
AT070TN84 V.1 Innolux 7.0 800×480
AT070TN90 Innolux 7.0 800×480
AT070TN92 V.3 Innolux 7.0 800×480
AT070TN93 Innolux 7.0 800×480
AT070TNA2 Innolux 7.0 1024×600
