| PartNumber | UG-2864KSYMG01 |
| Marca | WiseChip |
| mărimea | 1.54 |
| Aplicație | IA |
| Rezoluţie | 128×64 |
| Compoziţie | OLED |
| Luminozitate | 150 |
| CR | 10000:1 |
| Culori | Mono(Yellow) |
| Iluminare de fundal | self |
| Interfață | CPU/SPI/I²C |
| marca panoului | WiseChip |
| model de panou | UG-2864KSYMG01 |
| tip panou | PM-OLED , OLED |
| dimensiunea panoului | 1.54 inch |
| rezoluţie | 128×64 |
| Zonă activă | 35.052×17.516 mm |
| contur | 42.04×27.22 mm |
| suprafaţă | |
| luminozitatea | 150 cd/m² (Typ.) |
| Raport de contrast | 10000 : 1 (Typ.) |
| culorile afișajului | Mono(Yellow) |
| unghi de vedere | |
| driver ic | Built-in SSD1309 |
| interfață de semnal | 8-bit 6800/8080 parallel, 4-wire SPI, I²C |
| rohs: | |
| aplicarea | IA |
| UG-2864ASGPG01 | WiseChip | 2.4 | 128×64 |
| UG-2864ASWIG01 | WiseChip | 2.7 | 128×64 |
| UG-2864ASWPG01 | WiseChip | 2.4 | 128×64 |
| UG-2864ASYCG01 | WiseChip | 1.54 | 128×64 |
| UG-2864ASYDT01 | WiseChip | 2.7 | 128×64 |
| UG-2864ASYIG01 | WiseChip | 2.7 | 128×64 |
| UG-2864HLBEG01 | WiseChip | 0.96 | 128×64 |
| UG-2864HMBEG01 | WiseChip | 0.96 | 128×64 |
| UG-2864HSWEG01 | WiseChip | 0.96 | 128×64 |
| UG-2864KSYMG01 | WiseChip | 1.54 | 128×64 |
| FX050700DSCWDG12 | Data Image | 5.7 | |
| LB121S03-TL03 | LG Display | 12.1 | 800×600 |
| LQ121S1DG43 | SHARP | 12.1 | 800×600 |
| LQ9D340 | SHARP | 8.4 | 640×480 |
| NL6448AC30-10 | NLT | 9.4 | 640×480 |
| OEL9M0073-W-E | Other | 1.0 | 128×64 |
| TCG035QVLPDANN-GN50 | Kyocera | 3.5 | 320×240 |
| TM080SDH01 | Tianma | 8.0 | 800×600 |
| UG-2864ALBPG01 | WiseChip | 2.4 | 128×64 |
| UG-2864ASYIG01 | WiseChip | 2.7 | 128×64 |
