| PartNumber | TM101JDHG38 |
| Marca | TIANMA |
| mărimea | 10.1 |
| Aplicație | Industrial Medical I |
| Rezoluţie | 1280×800 |
| Compoziţie | LCM, a-Si TFT-LCD |
| Luminozitate | |
| CR | 800:1 |
| Culori | 262K/16.7M |
| Iluminare de fundal | 6S5P |
| Interfață | LVDS |
| producător | TIANMA |
| numele modelului | TM101JDHG38 |
| marimea ecranului | 10.1 inch |
| tipul de ecran | LCM, a-Si TFT-LCD |
| numărul de pixeli | 1280(RGB)×800 (WXGA) 149PPI |
| aranjament | RGB Vertical Stripe |
| zona activa (mm) | 216.96 × 135.6 (H×V) |
| contur (mm) | 231.22 × 150.6 × 6.6 (H×V×D) |
| zona rama (mm) | 219.96 × 138.6 (H×V) |
| tratament | Hard coating |
| luminanţă | 400 cd/m² (Typ.) |
| Raport de contrast | 800 : 1 (Typ.) (TM) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10) |
| raspuns | 25 (Typ.)(Tr+Td) ms |
| vedere buna la | Symmetry |
| modul de lucru | SFT, Normally Black, Transmissive |
| adâncimea culorii | 262K/16.7M 50% NTSC |
| lumina de fundal | 6S5P WLED , 30K hours , With LED Driver |
| masa | 276g |
| folosit pentru | Industrial Medical Imaging VOIP Phone |
| rată de reîmprospătare | 60Hz |
| touch screen | Without |
| tipul semnalului | LVDS (1 ch, 6/8-bit) , Connector 40 pins |
| alimentare cu tensiune | 3.3V (Typ.) |
| max. evaluări | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
