| PartNumber | TM050RDZG03-30 |
| Marca | TIANMA |
| mărimea | 5.0 |
| Aplicație | Industrial |
| Rezoluţie | 800×480 |
| Compoziţie | LCM, a-Si TFT-LCD |
| Luminozitate | |
| CR | 600:1 |
| Culori | 16.7M |
| Iluminare de fundal | 3S6P |
| Interfață | |
| producător | TIANMA |
| numele modelului | TM050RDZG03-30 |
| marimea ecranului | 5.0 inch |
| tipul de ecran | LCM, a-Si TFT-LCD |
| numărul de pixeli | 800(RGB)×480 (WVGA) 188PPI |
| aranjament | RGB Vertical Stripe |
| zona activa (mm) | 108 × 64.8 (H×V) |
| contur (mm) | 120.7 × 77.8 × 5.9 (H×V×D) |
| zona rama (mm) | 111.1 × 67.9 (H×V) |
| tratament | Antiglare, Hard coating (3H) |
| luminanţă | 1000 cd/m² (Typ.) |
| Raport de contrast | 600 : 1 (Typ.) (TM) |
| unghi de vedere | 70/70/50/70 (Typ.)(CR≥10) |
| raspuns | 20/30 (Typ./Max.)(Tr+Td) ms |
| vedere buna la | 12 o'clock |
| modul de lucru | TN, Normally White, Transmissive |
| adâncimea culorii | 16.7M 50% NTSC |
| lumina de fundal | 3S6P WLED , 50K hours |
| masa | TBD |
| folosit pentru | Industrial |
| rată de reîmprospătare | 60Hz |
| touch screen | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C |
