| PartNumber | TM035PDH53 |
| Marca | Tianma |
| mărimea | 3.5 |
| Aplicație | MPH |
| Rezoluţie | 320×480 |
| Compoziţie | LCM |
| Luminozitate | 300 |
| CR | 500:1 |
| Culori | 65K/262K |
| Iluminare de fundal | WLED |
| Interfață | CPU/RGB |
| marca panoului | TIANMA |
| model de panou | TM035PDH53 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 3.5 inch |
| rezoluţie | 320(RGB)×480 , HVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 48.96×73.44 mm |
| contur | 54.34×84.07×2.1 mm |
| suprafaţă | Clear |
| luminozitatea | 300 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Typ.) |
| culorile afișajului | 65K/262K , CIE193160% |
| timp de raspuns | 20 (Typ.)(Tr+Td) |
| unghi de vedere | 70/70/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | 6S1PWLEDWithout Driver |
| interfață de semnal | CPU/RGB, 45 pins |
| tensiune de intrare | 1.8/2.8 (Typ.)(IOVCC/VCC) |
| aplicarea | MPH |
| TM035KBH02 | Tianma | 3.5 | 320×240 |
| TM035KDH03 | Tianma | 3.5 | 320×240 |
| TM035KDH04 | Tianma | 3.5 | 320×240 |
| TM035KDH05 | Tianma | 3.5 | 320×240 |
| TM035KDH08 | Tianma | 3.5 | 320×240 |
| TM035KDH16-09 | Tianma | 3.5 | 320×240 |
| TM035NDH04 | Tianma | 3.5 | 272×480 |
| TM035PDH53 | Tianma | 3.5 | 320×480 |
| TM035PDZ15 | Tianma | 3.5 | 320×480 |
| TM035WBHG01 | Tianma | 3.5 | 480×640 |
| AMEJ006 | Samsung | 2.8 | 240×400 |
| AMS320FS03 | Samsung | 3.2 | 320×480 |
| BA060WV1-100 CELL | BOE | 6.0 | 480×854 |
| DLC0283FZG-7 | Other | 2.8 | 240×320 |
| H497TLB01 | AUO | 5.0 | 720×1280 |
| LH240Q29-SH04 | LG Display | 2.4 | 240×320 |
| LT032MDQ7000 | JDI | 3.2 | 360×480 |
| PJ035MA-02A | Innolux | 3.5 | 320×480 |
| TM020GDZ25 | Tianma | 2.0 | 176×220 |
| TM028HDH21 | Tianma | 2.8 | 240×320 |
