| PartNumber | DLC0283FZG-7 |
| Marca | Other |
| mărimea | 2.8 |
| Aplicație | MPH |
| Rezoluţie | 240×320 |
| Compoziţie | LCM |
| Luminozitate | 300 |
| CR | 400:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | CPU/RGB |
| marca panoului | DLC |
| model de panou | DLC0283FZG-7 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 2.8 inch |
| rezoluţie | 240(RGB)×320 , QVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 43.2×57.6 mm |
| contur | 50×70 mm |
| suprafaţă | |
| luminozitatea | 300 cd/m² (Typ.) |
| Raport de contrast | 400:1 (Typ.) |
| culorile afișajului | 262K , CIE193150% |
| timp de raspuns | 25 (Typ.)(Tr+Td) |
| unghi de vedere | 60/60/60/45 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 5S1PWLEDWithout Driver |
| interfață de semnal | CPU/RGB, 39 pins |
| tensiune de intrare | 1.8/2.8V (Typ.)(IOVCC/VCC) |
| aplicarea | MPH |
