| PartNumber | S50HW-YB06 |
| Marca | Samsung |
| mărimea | 50 |
| Aplicație | LCTV |
| Rezoluţie | 1365×768 |
| Compoziţie | PDP |
| Luminozitate | 630 |
| CR | 5000:1 |
| Culori | 1.07B |
| Iluminare de fundal | self |
| Interfață | LVDS |
| marca panoului | SAMSUNG SDI |
| model de panou | S50HW-YB06 |
| tip panou | PDP , PDP |
| dimensiunea panoului | 50 inch |
| rezoluţie | 1365(RGB)×768 , WXGA |
| Zonă activă | 1105.65×622.08 mm |
| contur | 1175.4×688 mm |
| suprafaţă | |
| luminozitatea | 630 cd/m² (Typ.) |
| Raport de contrast | 5000 : 1 (Typ.) |
| culorile afișajului | 1.07B (10-bit) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| interfață de semnal | LVDS (1 ch, 10-bit) + SPI, 30 pins |
| rohs: | |
| aplicarea | LCTV |
