| PartNumber | T260XVN01.4 |
| Marca | AUO |
| mărimea | 26.0 |
| Aplicație | LCTV |
| Rezoluţie | 1366×768 |
| Compoziţie | LCM |
| Luminozitate | 350 |
| CR | 3000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | AUO |
| model de panou | T260XVN01.4 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 26.0 inch |
| rezoluţie | 1366(RGB)×768 , WXGA |
| modul de afișare | AMVA3, Normally Black, Transmissive |
| Zonă activă | 575.769×323.712 mm |
| contur | 609.8×357.8 mm |
| suprafaţă | Antiglare (Haze 2%), Hard coating (3H) |
| luminozitatea | 350 cd/m² (Typ.) |
| Raport de contrast | 3000:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193168% |
| timp de raspuns | 6.5 (Typ.)(G to G) |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | LVDS (1 ch, 8-bit), 30 pins |
| tensiune de intrare | 12.0V (Typ.) |
| aplicarea | LCTV |
| T260XVN01.1 | AUO | 26.0 | 1366×768 |
| T260XVN01.4 | AUO | 26.0 | 1366×768 |
| T260XW01 V3 | AUO | 26.0 | 1280×768 |
| T260XW02 V0 | AUO | 26.0 | 1366×768 |
| T260XW02 V5 | AUO | 26.0 | 1366×768 |
| T260XW03 V3 | AUO | 26.0 | 1366×768 |
| T260XW04 V2 | AUO | 26.0 | 1366×768 |
| T260XW04 V7 | AUO | 26.0 | 1366×768 |
| T260XW04 V8 | AUO | 26.0 | 1366×768 |
| T260XW06 V2 | AUO | 26.0 | 1366×768 |
| LC320WUN-SCB1 | LG Display | 31.5 | 1920×1080 |
| LC420EUD-SDA1 | LG Display | 42 | 1920×1080 |
| LC470WUD-SCM1 | LG Display | 47 | 1920×1080 |
| LC650DUF-FGF1 | LG Display | 65 | 1920×1080 |
| T420HVN01.1 | AUO | 42 | 1920×1080 |
| T420HW05 V3 | AUO | 42 | 1920×1080 |
| T430QVN01.0 CELL | AUO | 43 | 3840×2160 |
| V201B1-L01 | Innolux | 20.1 | 1366×768 |
| V460H1-L09 | Innolux | 46 | 1920×1080 |
| V580HK1-LS6 | Innolux | 58 | 1920×1080 |
