| PartNumber | R196U2-L01 |
| Marca | Innolux |
| mărimea | 19.6 |
| Aplicație | MD |
| Rezoluţie | 1600×1200 |
| Compoziţie | LCM |
| Luminozitate | 600 |
| CR | 600:1 |
| Culori | 16.7M |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | CMO |
| model de panou | R196U2-L01 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 19.6 inch |
| rezoluţie | 1600(RGB)×1200 , UXGA |
| modul de afișare | IPS, Normally Black, Transmissive |
| Zonă activă | 398.4×298.8 mm |
| contur | 427×322.4×38.3 mm |
| suprafaţă | Antiglare (Haze 25%), Hard coating (3H) |
| luminozitatea | 600 cd/m² (Typ.) |
| Raport de contrast | 600:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193172% |
| timp de raspuns | 25/25 (Typ.)(Tr/Td) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 16 pcsCCFLEmbedded (Inverter) |
| interfață de semnal | LVDS (2 ch, 8-bit), 40 pins |
| tensiune de intrare | 12.0V (Typ.) |
| rohs: | |
| aplicarea | MD |
| LQ201U1LW18 | SHARP | 20.1 | 1600×1200 |
| NL160120AC27-37 | NLT | 21.3 | 1600×1200 |
| NL204153AC21-09 | NLT | 21.3 | 2048×1536 |
| NL204153BM21-05A | NLT | 21.3 | 2048×1536 |
| R190EFE-L61 | Innolux | 19.0 | 1280×1024 |
| R196U2-L01 | Innolux | 19.6 | 1600×1200 |
| R208RFE-L05 | Innolux | 20.8 | 2048×1536 |
| R300M1-L01 | Innolux | 30.0 | 4096×2560 |
| R300SFE-L02 | Innolux | 30.0 | 3280×2048 |
| VVX21F136J00 | Panasonic | 21.3 | 1600×1200 |
